1, connect the gas source:

调节减压阀0.4~0.6Mpa，检查系统有无漏气现象。

Adjust the pressure reducing valve to 0.4~0.6Mpa and check whether the system is leaking.

2、济南双组份打胶机将A、B组份胶桶就位，并与A、B胶泵的轴线对中。

2. The two component glue dispenser in Ji'nan will place A and B component barrels in the middle of the A and B glue pumps.

1)操作手动转阀，将A泵提升高，提升过程中观察各管路有无拉伸过紧处。

1) operate the manual rotary valve, lift the A pump to the highest level, and observe whether the pipelines are stretched too tight during the lifting process.

2)将胶桶放置在A泵压胶盘下，开启胶桶，将其中塑料袋外翻桶外，胶面塑料片取出。

2) place the plastic bucket under the A pump pressure plate, open the plastic bucket, turn the plastic bag to the outside of the barrel, and remove the plastic sheet.



3)使A泵压盘缓慢下降，压盘入桶时应使其与桶口对准，将压胶盘排气口打开，直到压盘接触胶面。待压盘内气体全部排放完并有少量胶从排气口溢出时，即可关闭排气阀。

3) make the pressure drop of the A pump slowly decrease. When the pressure plate is in the barrel, it should be aligned with the barrel mouth and open the exhaust port of the rubber disc until the pressure plate contacts the rubber surface. When the gas in the pressure plate is completely discharged and a small amount of glue flows out of the exhaust port, the exhaust valve can be closed.

4)开机试打胶：将主泵气源开关打开，按下胶枪开关，直A泵里空气排净枪口处出胶连续时停止。

4) boot test glue: open the main pump air source switch, press the glue gun switch, until the air in the A pump is clear, the muzzle ceased.

3、打胶操作：

3. Glue operation:

1)松开比例杠杆上的比例泵锁紧螺钉，将比例泵内外调整所需比例。只有当A胶和B胶的配比达到正常值时，才可进行下面的操作。

1) release the proportional screw on the proportional lever and adjust the proportion of the pump inside and outside to the required ratio. Only when the ratio of A glue and B glue reaches the normal value can the following operation be carried out.

2)置选择旋钮于A、B泵开，将胶枪出口对准两片玻璃的中缝，打开胶枪开关，以适当速度平稳地移动胶枪使玻璃槽内的双组份胶填满充实为佳。

2) put the selection knob on the A and B pump, aim the exit of the glue gun at the middle seam of the two glass, open the glue gun switch, and move the glue gun at the proper speed to fill the double component in the glass groove.
