Automatic dispensing machine is easy to operate, there are two main methods of operation, one is manual, the other is automatic. If manual is used, switch the automatic dispensing machine to manual. If for convenience, you can adjust the switch to the automatic position, as long as you adjust the air pressure and adjustment amount, you can adjust automatically. The dispensing speed is fast, the precision is high, and the needle mouth is not easy to be damaged. Applicable glue: AB glue, silica gel, red glue, UV glue, etc.

一、高速点药机ts-3000的特点:

The characteristics of TS-3000 are as follows: 1

1. CCD视觉自动定位系统;

1. CCD vision automatic positioning system;

2. 实现更小的点胶直径，更小单点直径可达250um;

2. Realize smaller dispensing diameter, and the minimum single point diameter can reach 250um;

3.成熟稳定的高速移动平台，速度可达1000mm/s，精度0.01mm;

3. mature and stable high-speed mobile platform, with the speed of 1000mm/s and the accuracy of 0.01mm;

4. 用于底部填充、圆片填充、零件涂层保护、粘接、密封等。

4. For bottom filling, disc filling, part coating protection, bonding, sealing, etc.

二世。如何使用高速点胶机:

II. How to use high speed dispenser:

步骤1:将调剂装置安装到装配线上;

Step 1: install the dispensing device on the assembly line;

将料筒插入配药装置的推杆中，将机架推入标准装配线。

Insert the barrel into the push rod of the dispensing device and push the rack into the standard assembly line.

第二步:快速将工件放入点胶机;

The second step: quickly put the workpiece into the dispensing machine;

开始标准生产线,工件沿流程标准生产线,工件将达到快速提取模块后,传入的光电检测开关检测传入,传入的块气缸上升,旋转气缸将弹出杆,拉缸驱动材料杆将点JiaoGong拉进夹具顶紧模块,夹块导杆上升同时,停止生活网上其他构件,夹具检测夹具自升式衬底得到光电开关,模块自升式气缸运动,夹具自升式基材拉杆将被发送到一个工件顶从流水生产线,原喷射完成的同时,旋转气缸驱动疏浚杆旋转90度,和疏浚泥缸返回位置,等待下一个泥。

Start the standard production line, the workpiece will follow the process standard production line, the workpiece will reach the fast extraction module, the incoming photoelectric detection switch detects the incoming, the incoming block cylinder rises, the rotating cylinder will pop up the rod, the pull cylinder drives the material rod to pull the point Jiaogong into the clamp tightening module, the clamp block guide rod rises at the same time, stops other components on the life net, and the clamp detection fixture automatically raises the substrate to get the photoelectric switch, When the module jack up cylinder moves, the clamp jack up base material pull rod will be sent to the top of a workpiece from the flow production line. When the original injection is completed, the rotating cylinder drives the dredging rod to rotate 90 degrees, and the dredging mud cylinder returns to the position, waiting for the next mud.

步骤3:固定工件，准备配药;

Step 3: fix the workpiece and prepare the dispensing;

工件离开生产线后，进入产品压缩模块，产品压缩模块开始工作。工件上升后，正方向由侧夹缸引导，使工件的长侧方向垂直于y轴。保证了两个橡胶阀与工件的相对位置精度，并将工件固定在产品压缩装置中。

After the workpiece leaves the production line, it enters the product compression module, and the product compression module starts to work. After the workpiece rises, the positive direction is guided by the side clamping cylinder, so that the long side direction of the workpiece is perpendicular to the Y axis. The relative position accuracy of the two rubber valves and the workpiece is ensured, and the workpiece is fixed in the product compression device.

步骤4:上胶工件;

Step 4: glue the workpiece;

调剂模块开始工作，调剂装置将胶水调剂到工件上。

The adjustment module starts to work, and the adjustment device adjusts the glue to the workpiece.

步骤5:快速将工件送出点胶机;

Step 5: quickly send the workpiece out of the dispensing machine;

产品合模装置,分配完成后松开工件,工件进入固定产品压缩模块模块,模块自升式气缸下降,夹块气缸下降,传入的块气缸上升,传入的光电检测开关检测传入,旋转气缸将弹出杆,排出气缸将一些JiaoGong夹具发出;由点胶部件回原生产线，流向下一站。

The product clamping device releases the workpiece after the distribution is completed. The workpiece enters the fixed top product compression module module. The module jack up cylinder descends, the clamp cylinder descends, the incoming block cylinder rises, the incoming photoelectric detection switch detects the incoming, the rotating cylinder pops up the rod, the exhaust cylinder sends out some Jiaogong clamps; the dispensing part returns to the original production line and flows to the next station.
